Amplifier 100% Duty Cycle, 403-450 MHz, Input 2-5W /Output 100W, 26 A, 13.8 Vdc. CRESCEND P10-2UL1-C5-001
Amplifier 100% Duty Cycle, 403-450 MHz, Input 2-5W /Output 100W, 26 A, 13.8 Vdc.
$1,954.16
- Description
- Additional information
Description
 Available Stock USA  |
|---|
Amplifier 100% Duty Cycle, 403-450 MHz, Input 2-5W /Output 100W, 26A, 13.8Vdc.
- Frequency Range: 403-450 MHz (UL).
- Operating Voltage: +13.8 VDC.
- Current Draw: 26 Amperes (Max).
- Duty Cycle: 100%.
- Power Input: See chart below.
- Power Output: 100 Watts, set at factory.
- Spurious & Harmonics: Meets FCC Requirements.
- Input/Output Impedance: 50 ohms (Nominal).
- Load VSWR Tolerance: VSWR Protected.
- Indicator LEDs: DC On, Low Output, High VSWR, High Temp.
- Alarm: Summary Alarm Pin.
- Input/Output Connector: Type N Female.
- Cooling Method: Fan Forced Air Over Heat sink.
- Operating Temp. Range: -30º C to +60º C.
- Storage & Transport: -40º C to +70º C.
- Humidity: 80% at +40º C (non-condensing).
- Altitude: 10,000 feet maximum.
Additional information
| Dimensions | 18 × 15 × 48 foot |
|---|---|
