Self-supporting Bow-type Drop Cable, 2FO ” 2 cores”, Outdoor Drop Cable, 2X5 mm, G657A2, FRP, LSZH Black Jacket, 6500 ft / drum LINKEDPRO BY EPCOM LP-FAB-GJVX(F)CH-A2-2FO/2KM
Self-supporting Bow-type Drop Cable, 2FO ” 2 cores”, Outdoor Drop Cable, 2X5 mm, G657A2, FRP, LSZH Black Jacket, 6500 ft / drum
$107.72
- Description
- Additional information
Description
 Available Stock USA  |
|---|
CHA21FO/215049-linkedpro_banner_fftx.png)
Description:
The optical fiber unit is positioned in the centre. Two parallel fiber reinforced plastics (FRP) are placed at the two sides. A steel wire as the additional strength member is also applied. Then, the cable is completed with a black LSZH sheath.
Features:
- Special Low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property
- Two parallel FRP/strength members ensure good performance of crush resistance to protect the fiber
- Simple structure, lightweight and high practicablity
- Novel flute design, easily strip, and splice, simplify the installation and maintenance
- Low smoke,zero halogen, and flame retardant sheath
- “Easy-Pull” internal spin system, for easy deployment and retraction of excess cable.
Product Mechanical performance:
- Fiber count: 2
- Cable Diameter mm: 2.0×5.0 ± 0.2
- Cable weight: 86.0 lbs
- Tensile Strength Long/Short term N: 300/600
- Crush Resistance Long/Short term N/1000mm: 1000/2200
Additional information
| Dimensions | - × - × - foot |
|---|---|
| Created: | 22/11/2024, 6:36 AM |
